Lexmoto LS-Z Euro 5 Overview

Other Information

Model Code :

ZS125-39-E5

Fuel Consumption :

90 mpg

Fuel Tank Capacity :

13 Litres

About the Lexmoto LS-Z Euro 5

Born in the neon flood-lit city streets of Shanghai, Lexmoto`s latest learner legal model is ready to make a bold statement on UK tarmac.

The LS-Z`s silhouette immediately captures attention with its sporty, well-proportioned lines, defined by the low-level exhaust and rear registration plate hugger that allows the sharp back end of the LS-Z to stand tall.

Embracing Chinese Street culture, the word "naked" is now emblazoned across the 13L fuel tank for the world to see; bringing extra character to a machine that wants its voice to be heard.

The reliable 125cc single cylinder engine produces consistant power through the rev-range. Paired with a 6-speed gearbox, you`ll find there`s plenty of punch getting to the rear wheel.

The USD front forks and rear monoshock are fairly firm but this only provides the rider with more confidence in the corners where the LS-Z feels incredibly balanced and secure.

USB charging comes standard, a huge plus point for commuters using external devices for GPS, whilst the crisp LCD digital display allows for easy peripheral viewing so you can concentrate on the road ahead.

Combined hydraulic disc brakes offer ample stopping power for the lightweight 125, with full LED lights providing even more safety and confidence at all times of the day.

Start your journey on an LS-Z today.

This product was added at 10:28am on Monday 01 November 2021
Last updated: Dec 21, 2024

Need parts for the Lexmoto LS-Z Euro 5?

CMPO are the offical parts supplier of all Lexmoto parts. In addition to this they also stock parts for all other brands in the Chinese Motorcycle Dealer repertoire.

Click here to visit CMPO Parts

Found Cheaper?

We're still better value! Don't get caught out, read why you should take care who you shop with.

Lexmoto LS-Z Euro 5 Specifications

Performance

Max Speed :

110 kph

Max Power :

9.5Kw at 9000rpm

Max Torque :

10.5Nm @ 7000 rpm

Engine and Transmission

Engine Size :

124 cc

Engine Type:

Single Cylinder, 4 Stroke, Water Cooled

Engine Brand :

158MI-2P

Bore x Stroke :

5.8 x 4.7

Compression Ratio :

12:1

Gear Type :

6 Speed

Clutch Type :

Hand Operated

Drive Type :

Chain

Start System :

Electric Start

Ignition Type :

EFI

Battery Voltage :

12v

Battery Capacity :

9

Wheel, Suspension and Brakes

Front Tyre :

100/80-17

Rear Tyre :

140/70-17

Tyre Model :

Tubeless

Front Suspension :

Inverted Forks

Rear Suspension :

Monoshock

Front Brake :

Hydraulic Disc

Rear Brake :

Hydraulic Disc

Dimensions

Seat Height :

770 mm

Wheelbase :

1350 mm

Overall Length :

2030 mm

Overall Width :

800 mm

Overall Height :

1070 mm

Mass in Running Order :

149 kg

This is the weight/mass of an unladen vehicle but one which has all fluids correct and present within. It includes fuel in the tank to a minimum of 90% full.

Maximum Laden Mass :

314 kg

This is the maximum operating weight/mass of the vehicle as specified by the manufacturer including the vehicle's chassis, body, engine, engine fluids, fuel, accessories, rider, pillion and cargo.

Lexmoto LS-Z Euro 5 Technical Data

Model Information

CAP/ABI Code

LXLZ013 CO6C EZB

Engine Settings

Capacity

124 cc

Compression Ratio

12:1

Stroke

4 Stroke

Valves per cylinder

4

Valve Train

DOHC

Engine Type

ZS158MI-2P

Cylinders

Single

Cooling

Liquid Cooled

Timing and Ignition

Spark Plug

CR9E

Spark Plug Gap

0.6-0.8mm

HT Coil Primary Resistance

0.5Ω

HT Coil Secondary Resistance (with cap)

14.5KΩ

Spark Plug Torque

20 Nm

Valve Clearances

Exhaust Valve (Metric)

0.04-0.06 mm

Inlet Valve (Metric)

0.04-0.06 mm

Fuel System

EFI System

Motronic (Bosch)

EFI Plug Location

Under pillion seat

Electrical

Battery Location

Left mid panel

Drive

Drive Type

Chain

Handling and Suspension

Fork Oil Volume

245 ml per leg

Rear Suspension

Mono

Front Pinch Bolt

20

Front Brake

Disc

Rear Brake

Disc

Front Suspension

USD

Fork Oil Grade

20w

Tyre Pressures

Front

36 psi

Rear

36 psi

Fluids

Engine Oil Viscosity

10w/40

Brake Fluid Grade

Dot 4

Engine Oil Grade

SJ or later

Engine Oil Volume

1000-1200 ml

Anti-Freeze Ratio

1:1

Torque Settings

Front Wheel Spindle

65 Nm

Swingarm Pivot Securing Nut

80 Nm

Front brake Caliper Bolts

45 Nm

Front Brake Disc Bolts

35 Nm

Rear Shock Absorber Lower Nut/Bolt

60 Nm

Rear brake disc bolt torque

35 Nm

Rear Wheel Spindle Nut

50 Nm

Oil Filter Cover Bolts

15 Nm

Rear Shock Absorber Upper Nut/Bolt

60 Nm

Rear Wheel Sprocket Retaining Nuts

50 Nm

Front Wheel Spindle Pinch Bolt

20 Nm

Oil Sump Drain Bolt

20 Nm

Lower yoke pinch bolts

30 Nm

Riders Footrest Bolt Torque

60 Nm

Upper Yoke Pinch Bolts

30 Nm

Handlebar Clamp Bolts

25 Nm

Exhaust Silencer Mounting Bolt/Nut

45 Nm
