ZN125T-8F-E5
125cc 4 Stroke
Lexmoto Titan 125 Euro 5 Overview
Other Information
- Model Code :
- ZN125T-8F-E5
- Fuel Tank Capacity :
- 5.5 Litres
About the Lexmoto Titan 125 Euro 5
In need of a reliable, hard-working, practical and easy to ride commuter scooter? Then the Lexmoto Titan will be just what you`re after. This affordable twist n` go scooter gets you from A to B with ease and comfort thanks to a large comfortable seat, with ample under-seat storage, easy-to-use controls and a lightweight 118kg for easy manoeuvrability. It`s large road presence and simple practicality, the Titan offers any rider a great value package.
This product was added at 6:15pm on Friday 18 September 2020
Last updated:
Dec 12, 2024
Need parts for the Lexmoto Titan 125 Euro 5?
CMPO are the offical parts supplier of all Lexmoto parts. In addition to this they also stock parts for all other brands in the Chinese Motorcycle Dealer repertoire.
Found Cheaper?
We're still better value! Don't get caught out, read why you should take care who you shop with.
Lexmoto Titan 125 Euro 5 Specifications
Performance
- Max Speed :
- 80 kph
- Max Power :
- 5.4Kw @ 7500
- Max Torque :
- 7.65Nm @ 6000rpm
Engine and Transmission
- Engine Size :
- 125 cc
- Engine Type:
- Single Cylinder, 4 Stroke, Air Cooled
- Engine Brand :
- GY6 -BN152QMI
- Bore x Stroke :
- 5.2 x 5.8
- Compression Ratio :
- 9.2:1
- Gear Type :
- Twist and Go
- Drive Type :
- Belt
- Start System :
- Electric / Kick Start
- Ignition Type :
- EFI
- Battery Voltage :
- 12
- Battery Capacity :
- 6Ah
Wheel, Suspension and Brakes
- Front Tyre :
- 130/60-13
- Rear Tyre :
- 130/60-13
- Tyre Model :
- Tubeless
- Front Suspension :
- Telescopic Forks
- Rear Suspension :
- Twin Shock Absorber
- Front Brake :
- Hydraulic Disc
- Rear Brake :
- Hydraulic Disc
Dimensions
- Seat Height :
- 780 mm
- Wheelbase :
- 1365 mm
- Overall Length :
- 1940 mm
- Overall Width :
- 700 mm
- Overall Height :
- 1160 mm
- Mass in Running Order :
- 118 kg
- Maximum Laden Mass :
- 278 kg
Lexmoto Titan 125 Euro 5 Technical Data
Model Information
- CAP/ABI Code
- LXTI013 SC A DYB
Power Output
- Max. Power
- 5.3 @ 7500 kW @ RPM
- Max. Torque
- 7.65 @ 6000 Nm @ RPM
Engine Settings
- Capacity
- 124 cc
- Compression Ratio
- 9.2:1
- Stroke
- 4 Stroke
- Valves per cylinder
- 2
- Cylinders
- Single
- Cooling
- Air Cooled
- Idle Speed
- 1600 min-1
- Max RPM
- 10000 rpm
- Bore x Stroke
- 124.65
Timing and Ignition
- Spark Plug
- CR7HSA
- Spark Plug Gap
- 0.6-0.7mm
Valve Clearances
- Exhaust Valve (Metric)
- 0.06-0.09 mm
- Inlet Valve (Metric)
- 0.05-0.08 mm
Handling and Suspension
- Rear Suspension
- Twin
- Front Disc Size
- 220 mm
- Front Brake
- Disc
- Rear Disc Size
- 190 mm
- Rear Brake
- Disc
- Front Suspension
- Telescopic
- Advanced Braking System
- Combined Braking
Tyre Pressures
- Front
- 32 psi
- Rear
- 32 psi
Fluids
- Engine Oil Viscosity
- SG
- Engine Oil Grade
- 10W40
- Engine Oil Volume
- 800-1000 ml
- Gearbox Oil Grade
- 85w/90
- Final drive oil quantity
- 120 ml
Torque Settings
- Rear brake disc bolt torque
- 20 +thread locking agent Nm
Lexmoto Titan 125 Euro 5 Gallery
** Pictures are for illustration purposes only
Lexmoto Titan 125 Euro 5 360° View
Black Blue
Back Red
Black Grey
Lexmoto Titan 125 Euro 5 User Manuals
