TR300T-P-E5
300cc 4 Stroke
Lexmoto Pegasus 300 Euro 5 Overview
Other Information
- Model Code :
- TR300T-P-E5
- Fuel Consumption :
- 60 mpg
- Fuel Tank Capacity :
- 13 Litres
About the Lexmoto Pegasus 300 Euro 5
Designed to be the ultimate maxi-scooter that puts style and comfort at the forefront of your journey, the Pegasus 300 is a serious machine for the modern-day rider who does not live to work, but works to live. Packed with features such as an ABS braking system, large LCD display and a 12v charging socket. There is no need to compromise on quality whilst maintaining unbeatable affordability. Now coming in two sleek, understated colour options, we welcome the Matt Black edition into the range; giving you the power to choose the light or dark side. The EURO5-compliant liquid-cooled 300cc engine packs a whole lot of punch that sees you gliding through traffic like you are riding the mythical beast itself. That is what dreams are made of.
This product was added at 4:03pm on Thursday 15 October 2020
Last updated:
May 8, 2025
Need parts for the Lexmoto Pegasus 300 Euro 5?
CMPO are the offical parts supplier of all Lexmoto parts. In addition to this they also stock parts for all other brands in the Chinese Motorcycle Dealer repertoire.
Found Cheaper?
We're still better value! Don't get caught out, read why you should take care who you shop with.
Lexmoto Pegasus 300 Euro 5 Specifications
Performance
- Max Speed :
- 125 kph
- Max Power :
- 19.5Kw @8000
- Max Torque :
- 24.5 Nm @ 7000rpm
Engine and Transmission
- Engine Size :
- 276 cc
- Engine Type:
- Single Cylinder, 4 Stroke, Water Cooled
- Engine Brand :
- IP73MN
- Bore x Stroke :
- 7.3 x 6.6
- Compression Ratio :
- 11.5:1
- Gear Type :
- Twist and Go
- Drive Type :
- Belt
- Start System :
- Electric Start
- Ignition Type :
- EFI
- Battery Voltage :
- 12
- Battery Capacity :
- 12Ah
Wheel, Suspension and Brakes
- Front Tyre :
- 120/70/15
- Rear Tyre :
- 140/70-14
- Tyre Brand :
- TIMSUN
- Tyre Model :
- Tubeless
- Front Suspension :
- Telescopic Forks
- Rear Suspension :
- Twin Shock Absorber
- Front Brake :
- Hydraulic Disc
- Rear Brake :
- Hydraulic Disc
Dimensions
- Seat Height :
- 780 mm
- Wheelbase :
- 1617 mm
- Overall Length :
- 2227 mm
- Overall Width :
- 786 mm
- Overall Height :
- 1291 mm
- Mass in Running Order :
- 177 kg
- Maximum Laden Mass :
- 327 kg
Lexmoto Pegasus 300 Euro 5 Technical Data
Model Information
- Minimum Licence Required
- A2 (UK Entitlement)
- Parking options
- Centre and Side Stand
- Fuel Tank Capacity
- 13 l
- CAP/ABI Code
- LXPE030 SC A CYB
- Odometer Reading
- Dual
- Speedo Type
- Digital
Power Output
- Max. Power
- 19.5@8000 kW @ RPM
- Max. Torque
- 24.5 @ 7000 Nm @ RPM
Engine Settings
- Capacity
- 276 cc
- Compression Ratio
- 11.5 : 1
- Stroke
- 4 Stroke
- Valve Train
- DOHC
- Engine Type
- 1P73MN
- Cylinders
- Single
- Cooling
- Liquid Cooled
- Max RPM
- 9000 rpm
Timing and Ignition
- Spark Plug
- CR9E
- Spark Plug Gap
- 0.7-1.0mm
Valve Clearances
- Exhaust Valve (Metric)
- 0.11-0.14 mm
- Inlet Valve (Metric)
- 0.08-0.11 mm
Handling and Suspension
- Front Pinch Bolt
- 13
- Front Disc Size
- 250 mm
- Front Brake
- Twin Disc
- ABS Sensor Gap Rear Wheel
- 0.8 mm
- Rear Disc Size
- 230 mm
- ABS sensor Gap Front Wheel
- 0.7mm mm
- Rear Brake
- Disc
Tyre Pressures
- Front
- 25 psi
- Rear
- 29 psi
- Front Tyre
- 120/70-15
- Rear Tyre
- 140/70-14
- Tyre Brand
- Timsun
- Tyre Type
- Tubeless
- Front Tyre Pressure With Pillion
- 29 psi
- Rear Tyre Pressure With Pillion
- 32 psi
Fluids
- Engine Oil Viscosity
- 10w/40
- Engine Oil Grade
- SG
- Gearbox Oil Volume
- 150 ml
- Final drive gear oil viscosity
- 85w/90
Torque Settings
- Front brake Caliper Bolts
- 48 Nm
Lexmoto Pegasus 300 Euro 5 Gallery
** Pictures are for illustration purposes only
Lexmoto Pegasus 300 Euro 5 360° View
White
Black
Lexmoto Pegasus 300 Euro 5 User Manuals
* Recommended Retail Prices
RRP Prices are inclusive of VAT and includes Full Assembly, Full Pre-delivery Inspection (PDI) and a 12-month warranty, but can vary according to different geographic locations as Dealers may incorporate more comprehensive warranty and service plans into their pricing and may also offer accessories or other services above standard sales. Prices in Scotland, NI and offshore islands may be higher. Government first registration fee and vehicle excise duty are not included and will be charged at the current rate except for the cost of the physical number plate, which will be included in the price of the vehicle.
