Lexmoto LXS 125 Euro 5 Overview

Other Information

Model Code :

TR125-GP2-E5

Fuel Consumption :

87 mpg

Fuel Tank Capacity :

10 Litres

About the Lexmoto LXS 125 Euro 5

At its heart sits a powerful single-cylinder 125cc liquid-cooled engine that is followed up with a hidden under-seat exhaust system that enhances not only the agile handling and performance but keeps the clean lines of the styled sport chassis. Stopping comes easy thanks to the twin-petal front discs. Even when it`s not moving the LXS demands attention due to its two bold colour options, grey & fluro and black & blue. The twin LED headlights make for a truly wicked front stance, the LXS is an aggressively styled motorcycle that offers the ultimate introduction to the world of motorcycling at an affordable price.

This product was added at 9:03am on Tuesday 25 August 2020
Last updated: Dec 21, 2024

Need parts for the Lexmoto LXS 125 Euro 5?

CMPO are the offical parts supplier of all Lexmoto parts. In addition to this they also stock parts for all other brands in the Chinese Motorcycle Dealer repertoire.

Click here to visit CMPO Parts

Found Cheaper?

We're still better value! Don't get caught out, read why you should take care who you shop with.

Lexmoto LXS 125 Euro 5 Specifications

Performance

Max Speed :

110 kph

Max Power :

10.3kW @8750rpm

Max Torque :

11.0 Nm @ 8000rpm

Engine and Transmission

Engine Size :

125 cc

Engine Type:

Single Cylinder, 4 Stroke, Water Cooled

Engine Brand :

158MI-2P

Bore x Stroke :

5.8 x 4.7

Compression Ratio :

12:1

Gear Type :

6 Speed

Clutch Type :

Hand Operated

Drive Type :

Chain

Start System :

Electric Start

Ignition Type :

EFI

Battery Voltage :

12

Battery Capacity :

7

Wheel, Suspension and Brakes

Front Tyre :

110/70-16

Rear Tyre :

140/70-16

Tyre Brand :

CHENG SHIN

Tyre Model :

Tubeless

Front Suspension :

Telescopic Forks

Rear Suspension :

Monoshock

Front Brake :

Hydraulic Disc

Rear Brake :

Hydraulic Disc

Dimensions

Seat Height :

790 mm

Wheelbase :

1313 mm

Overall Length :

1961 mm

Overall Width :

738 mm

Overall Height :

1077 mm

Mass in Running Order :

155 kg

This is the weight/mass of an unladen vehicle but one which has all fluids correct and present within. It includes fuel in the tank to a minimum of 90% full.

Maximum Laden Mass :

305 kg

This is the maximum operating weight/mass of the vehicle as specified by the manufacturer including the vehicle's chassis, body, engine, engine fluids, fuel, accessories, rider, pillion and cargo.

Lexmoto LXS 125 Euro 5 Technical Data

Model Information

CAP/ABI Code

LXLX013 TO6C DYB

Odometer Reading

Dual

Power Output

Max. Power

10.3KW@8750 kW @ RPM

Max. Torque

11.0 @ 6750 Nm @ RPM

Max. Speed

110 Km/h

Max. Speed

68 Mph

Engine Settings

Capacity

124 cc

Compression Ratio

12:1

Stroke

4 Stroke

Valves per cylinder

4

Valve Train

DOHC

Cylinders

Single

Cooling

Liquid Cooled

Idle Speed

1450 ^min-1

Max RPM

10000 rpm

Bore x Stroke

124.18

Timing and Ignition

Spark Plug

CR9E

Spark Plug Gap

0.6-0.8mm

HT Coil Primary Resistance

0.5Ω

HT Coil Secondary Resistance

6.75KΩ

Spark Plug Torque

12 Nm

Valve Clearances

Exhaust Valve (Metric)

0.15-0.20 mm

Inlet Valve (Metric)

0.10-0.15 mm

Fuel System

EFI System

Delphi MT05.3

EFI Plug Location

Left rear cowling

Electrical

Battery Location

Right mid panel

Drive

Drive Type

Chain

Handling and Suspension

Fork Oil Volume

350 ml per leg

Rear Suspension

Mono

Front Pinch Bolt

13Nm

Front Disc Size

299 mm

Front Brake

Disc

Rear Disc Size

240 mm

Rear Brake

Disc

Front Suspension

Telescopic

Advanced Braking System

Combined Braking

Fork Oil Grade

20w

Tyre Pressures

Front

32 psi

Rear

32 psi

Fluids

Engine Oil Viscosity

10W40

Brake Fluid Grade

Dot 4

Engine Oil Grade

SJ

Engine Oil Volume

900-1000 ml

Torque Settings

Front Wheel Spindle

50 Nm

Swingarm Pivot Securing Nut

80 Nm

Front brake Caliper Bolts

50 Nm

Front Brake Disc Bolts

40 Nm

Rear Shock Absorber Lower Nut/Bolt

60 Nm

Rear brake disc bolt torque

40 Nm

Rear Wheel Spindle Nut

80 Nm

Oil Filter Cover Bolts

8 Nm

Rear Shock Absorber Upper Nut/Bolt

60 Nm

Rear Wheel Sprocket Retaining Nuts

80 Nm

Front Wheel Spindle Pinch Bolt

13 Nm

Oil Sump Drain Bolt

20 Nm

Lower yoke pinch bolts

30 Nm

Riders Footrest Bolt Torque

30 Nm

Upper Yoke Pinch Bolts

25 Nm

Handlebar Clamp Bolts

20 Nm

Exhaust Silencer Mounting Bolt/Nut

12 Nm

Lexmoto LXS 125 Euro 5 Gallery

** Pictures are for illustration purposes only

Lexmoto LXS 125 Euro 5 360° View

Hold down the left mouse button on the bike and scroll side to side to rotate the bike.

• Black Blue
• Grey Yellow

Lexmoto LXS 125 Euro 5 User Manuals
