Lexmoto Detroit 125 Euro 5 Overview

Other Information

Model Code :

SR125-E5

Fuel Consumption :

123 mpg

Fuel Tank Capacity :

13 Litres

About the Lexmoto Detroit 125 Euro 5

The Detroit is the perfect combination of custom styling and accessibility into the world of two wheels.

Thanks to its low seat height of 720mm and high-rise handlebars you`ll find yourself comfortably cruising on a true modern classic.

Power comes from the reliable SOHC two-valve fuel-injected motor and incredibly smooth 5 speed gearbox to get you up to speeds of 65mph. If miles-per-gallon are high on your priority list, then you`re looking in the right place - the Detroit is one of the most economical motorcycles in the UK with over 100mpg being easily achievable.

Retro gets a contemporary upgrade with features such as adjustable pre-load rear shocks, digital/analogue display, braided brake lines, and the light cast alloy rims.

With two vintage inspired colour schemes to choose from the Detroit provides you with the perfect canvas to add your own flair and style.

This product was added at 12:03pm on Wednesday 17 November 2021
Last updated: Dec 21, 2024

Need parts for the Lexmoto Detroit 125 Euro 5?

CMPO are the offical parts supplier of all Lexmoto parts. In addition to this they also stock parts for all other brands in the Chinese Motorcycle Dealer repertoire.

Click here to visit CMPO Parts

Found Cheaper?

We're still better value! Don't get caught out, read why you should take care who you shop with.

Lexmoto Detroit 125 Euro 5 Specifications

Performance

Max Speed :

104 kph

Max Power :

7.0kW@8500rpm

Max Torque :

9.0Nm@6500rpm

Engine and Transmission

Engine Size :

124 cc

Engine Type:

Single Cylinder, 4 Stroke, Air Cooled

Engine Brand :

152FMI-5P

Bore x Stroke :

5.24 x 5.78

Compression Ratio :

9.2:1

Gear Type :

5 Speed

Clutch Type :

Hand Operated

Drive Type :

Chain

Start System :

Electric Start

Ignition Type :

EFI/ECU

Battery Voltage :

12

Battery Capacity :

9

Wheel, Suspension and Brakes

Front Tyre :

90/90-18

Rear Tyre :

140/90-15

Tyre Model :

Tubeless

Front Suspension :

Telescopic Forks

Rear Suspension :

Twin Shock Absorber

Front Brake :

Hydraulic Disc

Rear Brake :

Hydraulic Disc

Dimensions

Seat Height :

720 mm

Wheelbase :

1380 mm

Overall Length :

2061 mm

Overall Width :

835 mm

Overall Height :

1105 mm

Mass in Running Order :

141 kg

This is the weight/mass of an unladen vehicle but one which has all fluids correct and present within. It includes fuel in the tank to a minimum of 90% full.

Maximum Laden Mass :

291 kg

This is the maximum operating weight/mass of the vehicle as specified by the manufacturer including the vehicle's chassis, body, engine, engine fluids, fuel, accessories, rider, pillion and cargo.

Lexmoto Detroit 125 Euro 5 Technical Data

Model Information

CAP/ABI Code

LXDE013 CU5C FZB

Engine Settings

Capacity

124.6 cc

Stroke

4 Stroke

Valves per cylinder

2

Valve Train

SOHC

Engine Type

ZS125FMI-P

Cylinders

Single

Cooling

Air Cooled

Idle Speed

1500 ^min-1

Timing and Ignition

Spark Plug

CPR8EA

HT Coil Primary Resistance

1Ω

HT Coil Secondary Resistance (with cap)

14.5KΩ

Spark Plug Torque

15 Nm

Valve Clearances

Exhaust Valve (Metric)

0.15-0.20 mm

Inlet Valve (Metric)

0.10-0.15 mm

Fuel System

EFI System

Delphi

EFI Plug Location

Next to ECU

Drive

Transmission

Manual - 5 Speed

Handling and Suspension

Fork Oil Volume

325 ml per leg

Fork Oil Grade

10w

Tyre Pressures

Front

32 psi

Rear

32 psi

Fluids

Engine Oil Viscosity

10w/40

Engine Oil Grade

SJ or later

Engine Oil Volume

850-1000 ml

Torque Settings

Front Wheel Spindle

80 Nm

Swingarm Pivot Securing Nut

90 Nm

Front brake Caliper Bolts

50 Nm

Front Brake Disc Bolts

30 Nm

Rear Shock Absorber Lower Nut/Bolt

40 Nm

Rear brake disc bolt torque

30 Nm

Rear Wheel Spindle Nut

80 Nm

Rear Shock Absorber Upper Nut/Bolt

40 Nm

Rear Wheel Sprocket Retaining Nuts

70 Nm

Oil Sump Drain Bolt

22 Nm

Lower yoke pinch bolts

30 Nm

Riders Footrest Bolt Torque

50 Nm

Upper Yoke Pinch Bolts

30 Nm

Handlebar Clamp Bolts

15 Nm

Exhaust Silencer Mounting Bolt/Nut

40 Nm
