Lexmoto ZSB 125 Euro 5 Overview

Other Information

Model Code :

SK125-8-E5

Fuel Tank Capacity :

13 Litres

About the Lexmoto ZSB 125 Euro 5

Traditional, minimalistic bike design is paired with a smooth 4 stroke engine, easy-to-use controls, handy luggage rack and comfortable seat. It may be simplistic but the ZSB is packed with features like combined braking, a large 15-litre fuel tank and telescopic front forks. The ZSB is ideal for new riders and experienced riders alike and offers a no-nonsense motorcycle for an outstanding price that is difficult to top!

This product was added at 8:46am on Friday 09 October 2020
Last updated: Dec 21, 2024

Need parts for the Lexmoto ZSB 125 Euro 5?

CMPO are the offical parts supplier of all Lexmoto parts. In addition to this they also stock parts for all other brands in the Chinese Motorcycle Dealer repertoire.

Click here to visit CMPO Parts

Found Cheaper?

We're still better value! Don't get caught out, read why you should take care who you shop with.

Lexmoto ZSB 125 Euro 5 Specifications

Performance

Max Speed :

90 kph

Max Power :

8.6kW @ 9000rpm

Max Torque :

9.6Nm @ 8000rpm

Engine and Transmission

Engine Size :

125 cc

Engine Type:

Single Cylinder, 4 Stroke, Air Cooled

Engine Brand :

157FMI-D

Bore x Stroke :

5.65 x 4.96

Compression Ratio :

9.5:1

Gear Type :

5 Speed

Clutch Type :

Hand Operated

Drive Type :

Chain

Start System :

Electric Start

Ignition Type :

EFI

Battery Voltage :

12

Battery Capacity :

9

Wheel, Suspension and Brakes

Front Tyre :

3.00-18

Rear Tyre :

110/90-16

Tyre Model :

Tubed

Front Suspension :

Telescopic Forks

Rear Suspension :

Twin Shock Absorber

Front Brake :

Hydraulic Disc

Rear Brake :

Hydraulic Disc

Dimensions

Seat Height :

740 mm

Wheelbase :

1295 mm

Overall Length :

2000 mm

Overall Width :

800 mm

Overall Height :

1130 mm

Mass in Running Order :

125 kg

This is the weight/mass of an unladen vehicle but one which has all fluids correct and present within. It includes fuel in the tank to a minimum of 90% full.

Maximum Laden Mass :

275 kg

This is the maximum operating weight/mass of the vehicle as specified by the manufacturer including the vehicle's chassis, body, engine, engine fluids, fuel, accessories, rider, pillion and cargo.

Lexmoto ZSB 125 Euro 5 Technical Data

Model Information

Minimum Licence Required

CBT or A1 (UK Entitlement)

Parking options

Centre and Side Stand

Shipping State

SKD - Semi Knocked Down

CAP/ABI Code

LXZB013E5CO5C GYB

Odometer Reading

Dual

Speedo Type

Digital

Build Difficulty

2 - Straight Forward (Out of 5)

Engine Settings

Capacity

125 cc

Valves per cylinder

2

Cylinders

Single

Cooling

Air Cooled

Valve Clearances

Exhaust Valve (Metric)

0.04-0.06 mm

Inlet Valve (Metric)

0.04-0.06 mm

Fuel System

EFI System

Delphi

Handling and Suspension

Fork Oil Volume

180 ml per leg

Tyre Pressures

Front

33 psi

Rear

33 psi

Fluids

Engine Oil Grade

SAE 10W 40

Engine Oil Volume

1000 ml

Lexmoto ZSB 125 Euro 5 Gallery

** Pictures are for illustration purposes only

Lexmoto ZSB 125 Euro 5 360° View

• Blue
• Grey

Lexmoto ZSB 125 Euro 5 User Manuals
