KY500X-E5

471cc 4 Stroke

Black Blue Red

RRP £4,999.99*

TRADE CALL



Lexmoto Pioneer 500X Euro 5 Overview

Other Information
Model Code :
KY500X-E5
Fuel Consumption :
55 mpg
Fuel Tank Capacity :
20 Litres

About the Lexmoto Pioneer 500X Euro 5

It`s time to discover new paths on Lexmoto`s new A2-compatiable adventure tourer.

Instantly broaden your horizons with a machine that can take you anywhere you can point at on a map. Built to effortlessly glide on long distance tours, slice through morning traffic, or tackle the loosest of terrain, the Pioneer 500X is your new one-bike that does it all.

At its heart is a perky 471cc twin cylinder engine and BOSCH ECU that delivers smooth low-end torque when manoeuvring in tight situations or up steep inclines but expect high performance top end power that`ll have you flicking the bike into every S-bend.

Don`t just sit on the bike, sit in it. With a seat height of 820mm that cradles you comfortably between the 20L tank and pillion seat; you`ll feel secure at any speed, on any terrain. Couple that with the multi-adjustable KYB front & rear suspension and tubeless Metzeler Cross-tourer tyres that wrap the off-road focused spoked rims, and you have yourself an extremely capable machine.

Braking performance is top-tier thanks to Nissin`s dual 298mm floating front discs and two-piston calliper front setup, with a single 240mm floating disc and single calliper to bring up the rear. Choose how you want the bike to stop with the adjustable ABS, allowing you to disconnect the rear ABS for when you need that extra feel at the back wheel.

With all that power comes great responsibility - it`s down to you to set your riding mode, Safe or Sport. We recommend using the Safe mode when riding at slower speeds, on loose gravel, or in the rain. This alters the throttle and fuelling response to be softer and prevent loss of traction through the tyres onto the road surface. Find yourself on an open B-road or fast flowing motorway traffic then it`s time to engage Sport mode for added performance.

The Pioneer comes packed full of features that you should expect on any high-end adventure motorcycle with a USB and 12v charging port, adjustable front screen, hand guards, centre stand, grab rail and luggage rack, crash protection, aluminium bash plate and swingarm, LED lighting all-round, and a digital/analogue display unit.

What`s holding you back now? Get out there on the Pioneer 500X!


This product was added at 11:38am on Monday 26 July 2021
Last updated: Mar 19, 2024


CMPO Parts

Need parts for the Lexmoto Pioneer 500X Euro 5?


CMPO are the offical parts supplier of all Lexmoto parts. In addition to this they also stock parts for all other brands in the Chinese Motorcycle Dealer repertoire.

Click here to visit CMPO Parts


Found Cheaper?

We're still better value! Don't get caught out, read why you should take care who you shop with.

Lexmoto Pioneer 500X Euro 5 Specifications

Performance
Max Speed :
150 kph
Max Power :
32.5KW @ 8500rpm
Max Torque :
40.29Nm @ 6500rpm
Engine and Transmission
Engine Size :
471 cc
Engine Type:
Twin Cylinder, 4 Stroke, Water Cooled
Engine Brand :
Z267MR
Bore x Stroke :
471
Compression Ratio :
10.7:1
Gear Type :
6 Speed
Clutch Type :
Hand Operated
Drive Type :
Chain
Start System :
Electric Start
Ignition Type :
EFI
Battery Voltage :
12v
Battery Capacity :
9
Wheel, Suspension and Brakes
Front Tyre :
110/80-19
Rear Tyre :
150/70-17
Tyre Model :
Tubeless
Front Suspension :
Telescopic Forks
Rear Suspension :
Monoshock
Front Brake :
Hydraulic Disc
Rear Brake :
Hydraulic Disc
Dimensions
Seat Height :
820 mm
Wheelbase :
1479 mm
Overall Length :
2200mm mm
Overall Width :
935 mm
Overall Height :
1400mm mm
Mass in Running Order :
206 kg
This is the weight/mass of an unladen vehicle but one which has all fluids correct and present within. It includes fuel in the tank to a minimum of 90% full.
Maximum Laden Mass :
366 kg
This is the maximum operating weight/mass of the vehicle as specified by the manufacturer including the vehicle's chassis, body, engine, engine fluids, fuel, accessories, rider, pillion and cargo.

Lexmoto Pioneer 500X Euro 5 Technical Data

Model Information
Length
2200 mm
Fuel Tank Capacity
20 l
Width
935 mm
Wheelbase
1479 mm
Power Output
Max. Power
3205KW at 8500rpm kW @ RPM
Max. Torque
40.29Nm at 6500rpm Nm @ RPM
Max. Speed
150 Km/h
Engine Settings
Capacity
471 cc
Stroke
4 Stroke
Cylinders
Parallel-Twin
Cooling
Liquid Cooled
Bore x Stroke
471.03
Timing and Ignition
Spark Plug
CPR8EA
Spark Plug Gap
0.8 - 0.9
Drive
Transmission
Manual - 6 Speed
Drive Type
Chain
Handling and Suspension
Rear Suspension
Mono
Front Brake
Disc
Rear Brake
Disc
Front Suspension
USD
Advanced Braking System
Anti-Lock Braking
Tyre Pressures
Front
33.5 psi
Rear
36.5 psi
Front Tyre
110/80/R19
Rear Tyre
150/70/R17

Lexmoto Pioneer 500X Euro 5 Gallery



** Pictures are for illustration purposes only

Lexmoto Pioneer 500X Euro 5 360° View

Hold down the left mouse button on the bike and scroll side to side to rotate the bike.
0%

    * Recommended Retail Prices

    RRP Prices are inclusive of VAT and includes Full Assembly, Full Pre-delivery Inspection (PDI) and a 12-month warranty, but can vary according to different geographic locations as Dealers may incorporate more comprehensive warranty and service plans into their pricing and may also offer accessories or other services above standard sales. Prices in Scotland, NI and offshore islands may be higher. Government first registration fee and vehicle excise duty are not included and will be charged at the current rate except for the cost of the physical number plate, which will be included in the price of the vehicle.
