Kiden Pisces 125 Overview
Other Information
- Model Code :
- KD125-K
About the Kiden Pisces 125
Delivering the very best in affordable quality Lexmoto bring you the Kiden range.If you want the styling of a cruiser with comfortable commuter credentials then the Pisces is going to be the bike for you! The model uses a reliable 4 stroke overhead cam engine which provides a smooth and enjoyable riding experience. The model uses a twin shock rear which delivers stable handling. When combined with the disc brake front and rear the Pisces is sure to inspire confidence from new riders. With modern design elements and a superb quality of finish the Pisces is sure to turn heads and inspire many adventures.
This product was added at 12:02pm on Monday 23 January 2017
Last updated:
Mar 19, 2024
Need parts for the Kiden Pisces 125?
CMPO are the offical parts supplier of all Lexmoto parts. In addition to this they also stock parts for all other brands in the Chinese Motorcycle Dealer repertoire.
Found Cheaper?
We're still better value! Don't get caught out, read why you should take care who you shop with.
Kiden Pisces 125 Specifications
Performance
- Max Speed :
- 90 kph
- Max Power :
- 8kw @ 9000
Engine and Transmission
- Engine Size :
- 124 cc
- Engine Type:
- Single Cylinder, 4 Stroke, Air Cooled
- Engine Brand :
- KD156FMI-E
- Gear Type :
- 1 Down - 4 Up
- Clutch Type :
- Hand Operated
- Drive Type :
- Chain
- Start System :
- Electric Start
- Ignition Type :
- EFI
Wheel, Suspension and Brakes
- Front Tyre :
- 90/90-17
- Rear Tyre :
- 130/70-17
- Front Suspension :
- Telescopic Forks
- Rear Suspension :
- Twin Shock Absorber
- Front Brake :
- Hydraulic Disc
- Rear Brake :
- Hydraulic Disc
Dimensions
- Seat Height :
- 750 mm
- Wheelbase :
- 1310 mm
- Overall Length :
- 1993 mm
- Overall Width :
- 750 mm
- Overall Height :
- 1130 mm
- Mass in Running Order :
- 130 kg
- Maximum Laden Mass :
- 280 kg
Kiden Pisces 125 Technical Data
Model Information
- Minimum Licence Required
- CBT or A1 (UK Entitlement)
- Parking options
- Centre and Side Stand
- Shipping State
- SKD - Semi Knocked Down
- Fuel Tank Capacity
- 18 l
- Odometer Reading
- Dual
- Speedo Type
- Digital
- Build Difficulty
- 2 - Straight Forward (Out of 5)
Engine Settings
- Stroke
- 4 Stroke
- Valve Train
- OHC
- Cylinders
- Single
- Cooling
- Air Cooled
Fuel System
- EFI System
- Mikuni
- EFI Plug Location
- Under Seat
Valve Clearances
- Exhaust Valve (Metric)
- 0.07-0.09 mm
- Inlet Valve (Metric)
- 0.06-0.08 mm
Electrical
- Battery Location
- Behind Right Lower Panel
Fluids
- Engine Oil Grade
- 10w40
- Engine Oil Volume
- 1000 ml
Kiden Pisces 125 Gallery
** Pictures are for illustration purposes only
Kiden Pisces 125 360° View
Kiden Pisces 125 Downloads
A6 Bike brochure for Kiden Pices 125
Size: 1.1
