Lexmoto Assault 125 Euro 5 Overview

Other Information

Model Code :

HJ125-J-E5

Fuel Consumption :

100 mpg

Fuel Tank Capacity :

15 Litres

About the Lexmoto Assault 125 Euro 5

Switch up your daily commute and get where you want, when you want, with the Lexmoto Assault. Built around a smooth 4-stroke overhead cam engine the Assault will take on any terrain with ease. Riding is simple with a comfortable seat, sturdy telescopic forks and easy-to-use controls. Plus, stopping is easy too, thanks to combined braking and quality hydraulic disc`s. Ideal for riders looking for a comfortable riding experience no matter the conditions.

This product was added at 12:26pm on Thursday 25 March 2021
Last updated: Dec 21, 2024

Need parts for the Lexmoto Assault 125 Euro 5?

CMPO are the offical parts supplier of all Lexmoto parts. In addition to this they also stock parts for all other brands in the Chinese Motorcycle Dealer repertoire.

Click here to visit CMPO Parts

Found Cheaper?

We're still better value! Don't get caught out, read why you should take care who you shop with.

Lexmoto Assault 125 Euro 5 Specifications

Performance

Max Speed :

100 kph

Max Power :

8.0kw at 9000rpm

Max Torque :

9.01@ 7500rpm

Engine and Transmission

Engine Size :

125 cc

Engine Type:

Single Cylinder, 4 Stroke, Air Cooled

Engine Brand :

156FMI-E

Bore x Stroke :

5.65 x 4.96

Compression Ratio :

9.5±0.1:1

Gear Type :

5 Speed

Clutch Type :

Hand Operated

Drive Type :

Chain

Start System :

Electric Start

Ignition Type :

EFI

Battery Voltage :

12v

Battery Capacity :

7

Wheel, Suspension and Brakes

Front Tyre :

3.00-17

Rear Tyre :

130/70-17

Tyre Model :

Tubed

Front Suspension :

Telescopic Forks

Rear Suspension :

Twin Shock Absorber

Front Brake :

Hydraulic Disc

Rear Brake :

Hydraulic Disc

Dimensions

Seat Height :

780 mm

Wheelbase :

1310 mm

Overall Length :

1980 mm

Overall Width :

766 mm

Overall Height :

1080 mm

Mass in Running Order :

130 kg

This is the weight/mass of an unladen vehicle but one which has all fluids correct and present within. It includes fuel in the tank to a minimum of 90% full.

Maximum Laden Mass :

280 kg

This is the maximum operating weight/mass of the vehicle as specified by the manufacturer including the vehicle's chassis, body, engine, engine fluids, fuel, accessories, rider, pillion and cargo.

Lexmoto Assault 125 Euro 5 Technical Data

Model Information

Length

1980 mm

CAP/ABI Code

LXAS013E5DU6C HYB

Fuel Consumption

102 mpg

Width

766 mm

Wheelbase

1310 mm

Height

1080 mm

Power Output

Max. Power

8.0Kw @ 9000rpm kW @ RPM

Max. Torque

9.0Nm @ 7500rpm Nm @ RPM

Engine Settings

Capacity

124 cc

Stroke

4 Stroke

Valves per cylinder

2

Engine Type

KD156FMI-E

Cylinders

Single

Cooling

Air Cooled

Bore x Stroke

124.36

Timing and Ignition

Spark Plug

CPR6E

Spark Plug Gap

0.5-0.7mm

Spark Plug Resistance

10KΩ

Valve Clearances

Exhaust Valve (Metric)

0.07-0.09 mm

Inlet Valve (Metric)

0.06-0.08 mm

Fuel System

EFI System

Delphi MT05.3

Handling and Suspension

Rear Suspension

Mono

Front Disc Size

240 mm

Front Brake

Disc

Rear Brake

Disc

Front Suspension

Telescopic

Tyre Pressures

Front

29 psi

Rear

32 psi

Front Tyre

3.00-17

Rear Tyre

130/70-17

Fluids

Engine Oil Viscosity

10w40

Engine Oil Volume

900-1000 ml

Lexmoto Assault 125 Euro 5 Gallery

** Pictures are for illustration purposes only

Lexmoto Assault 125 Euro 5 360° View

• Blue
• Grey
• Black

Lexmoto Assault 125 Euro 5 User Manuals
