Lexmoto Valiant 125 EFI Overview

Other Information

Model Code :

XF125R-E4

About the Lexmoto Valiant 125 EFI

Motorcycling is a near spiritual experience. Feeling the wind flow around you as you carve a route through the rolling landscapes you can understand what it is to ride a motorcycle. The Lexmoto Valiant provides a traditional experience that focuses on the heart of riding on two wheels. Now revised as a fuel injected and combined braking model the Valiant has seen a host of changes including USD front suspension, Revised rear disc brake, Fuel indicator and revised styling whilst still maintaining an awesome price. A smooth 4 stroke motor provides a reliable engine with a sound that is refined through a stainless pea-shooter style exhaust. With classic Cafe racer styling you can turn heads and recreate the nostalgia of British motorcycling. Whether you choose the Black version with its solo humped seat and gold decals or the Red version with a brat style dual seat you can be assured of a truly unforgettable riding experience.

This product was added at 12:02pm on Tuesday 24 January 2017
Last updated: Feb 21, 2019

Need parts for the Lexmoto Valiant 125 EFI?

CMPO are the offical parts supplier of all Lexmoto parts. In addition to this they also stock parts for all other brands in the Chinese Motorcycle Dealer repertoire.

Click here to visit Chinese Motorcycle Parts Online

Found Cheaper?

We're still better value! Don't get caught out, read why you should take care who you shop with.

Lexmoto Valiant 125 EFI Specifications

Performance

Max Speed :

105 kph

Max Power :

7.3Kw @ 8500

Engine and Transmission

Engine Size :

125 cc

Engine Type:

Single Cylinder, 4 Stroke, Air Cooled

Engine Brand :

K157FMI - Suzuki GS

Bore x Stroke :

57 x 48.8

Compression Ratio :

9.5:1

Gear Type :

1 Down - 4 Up

Clutch Type :

Hand Operated

Drive Type :

Chain

Start System :

Electric Start

Ignition Type :

CDI

Wheel, Suspension and Brakes

Front Tyre :

110/70-17

Rear Tyre :

130/70-17

Tyre Brand :

Kingstone

Front Suspension :

Upside Down Forks

Rear Suspension :

Twin Shock Absorber

Front Brake :

Hydraulic Disc

Rear Brake :

Hydraulic Disc

Dimensions

Seat Height :

760 mm

Wheelbase :

1340 mm

Overall Length :

1940 mm

Overall Width :

835 mm

Overall Height :

1080 mm

Mass in Running Order :

118 kg

This is the weight/mass of an unladen vehicle but one which has all fluids correct and present within. It includes fuel in the tank to a minimum of 90% full.

Maximum Laden Mass :

285 kg

This is the maximum operating weight/mass of the vehicle as specified by the manufacturer including the vehicle's chassis, body, engine, engine fluids, fuel, accessories, rider, pillion and cargo.

Lexmoto Valiant 125 EFI Technical Data

Model Information

Speedo Type

Analogue

Odometer Reading

Kilometers

Parking options

Centre and Side Stand

Build Difficulty

2 - Straight Forward (Out of 5)

Shipping State

SKD - Semi Knocked Down

Power Output

Rated Max. Power

7.3 kW

@RPM

8500 ^min-1

Engine Settings

Cylinders

Single

Stroke

4 Stroke

OHC or OHV

OHC

Cooling

Air Cooled

Fuel System

Fuel Tank Capacity

14 l

EFI System

Delphi

EFI Plug Location

Under Seat

Valve Clearances

Exhaust Valve (Metric)

0.05-0.06 mm

Inlet Valve (Metric)

0.04-0.05 mm

Electrical

Battery Location

Behind Right Lower Panel

Handling and Suspension

Fork Oil Volume

300 ml per leg

Fork Oil Grade

5w

Tyre Pressures

Front

36 psi

Rear

40 psi

Fluids

Engine Oil Grade

10w40

Engine Oil Volume

1200 ml
